Introducing Absolute Quantities

Until now, mp-units forced users to choose between points (no arithmetic) and deltas (no physical semantics) — missing the most common case: a non-negative absolute amount.

An absolute quantity represents an absolute amount of a physical property — measured from a true, physically meaningful zero. Examples include mass in kilograms, temperature in Kelvin, or length in meters (as a size, not a position). Such quantities live on a ratio scale and are anchored at a physically meaningful zero; negative values are typically meaningless.

Absolute quantities stand in contrast to:

• Affine points (e.g., \(20\ \mathrm{°C}\), \(100\ \mathrm{m}\ \mathrm{AMSL}\)) — values measured relative to an arbitrary or conventional origin.
• Deltas (e.g., \(10\ \mathrm{K}\), \(–5\ \mathrm{kg}\)) — differences between two values.

Arithmetic on absolute quantities behaves like ordinary algebra: addition, subtraction, and scaling are well-defined and map naturally to physical reasoning. This article proposes making absolute quantities the default abstraction in mp-units V3, reflecting how scientists express equations in practice.

---

Note: Revised on May 12, 2026 for clarity, accuracy, and completeness.

Background

Affine Space Recap

Until now, mp-units modeled two fundamental abstractions:

• Points – represented by quantity_point in V2
• Deltas – represented by quantity

Info

More information on this subject can be found in the Affine Space chapter.

This design works but is sometimes awkward: users often misuse quantity_point to represent absolute magnitudes (e.g., total mass), losing arithmetic and printability. Conversely, using deltas everywhere hides physical intent and allows nonsensical operations.

The new absolute quantity abstraction aims to bridge that gap.

Quantity abstractions in physics

Below is a summary table comparing the three main quantity abstractions:

Feature	Point	Absolute	Delta
Physical Model	Interval Scale	Ratio Scale	Difference
Example	\(20\ \mathrm{°C}\), \(100\ \mathrm{m}\ \mathrm{AMSL}\)	\(293.15\ \mathrm{K}\), \(100\ \mathrm{kg}\)	\(10\ \mathrm{K}\), \(-5\ \mathrm{kg}\)
Has True Zero?	No (arbitrary/conventional)	Yes (physical)	N/A
Allows Negative?	Yes (below arbitrary origin)	No (opt-in)	Yes (direction matters)
Addition (A + A)	❌ Error (\(20\ \mathrm{°C} + 10\ \mathrm{°C}\))	✅ Absolute (\(10\ \mathrm{kg} + 5\ \mathrm{kg}\))	✅ Delta
Subtraction (A − A)	✅ Delta (\(30\ \mathrm{°C} - 10\ \mathrm{°C}\))	✅ Delta (\(50\ \mathrm{kg} - 5\ \mathrm{kg}\))	✅ Delta
Multiplication (k×A)	❌ Error (\(2 \times 20\ \mathrm{°C}\))	✅ Absolute (\(2 \times 10\ \mathrm{kg}\))	✅ Delta (\(-2 \times 5\ \mathrm{m}\))
Division (A / A)	❌ Error	✅ Scalar (\(10\ \mathrm{kg} / 5\ \mathrm{kg}\))	✅ Scalar (ratio)
A + Delta	✅ Point (shift)	✅ Absolute	✅ Delta
API	quantity<point<...>>	quantity<...>	quantity<delta<...>>

This table summarizes the key differences in semantics, API, and physical meaning for each abstraction. Use it as a quick reference when deciding which concept to use in your code.

Motivation

This section explains the driving reasons for introducing absolute quantities. It highlights the practical pain points, limitations, and sources of confusion in the current model, motivating the need for a new abstraction.

Current Pain Points

1. Limited arithmetic for points – Points can’t be multiplied, divided, or accumulated. This often forces the users to convert the quantity point to a delta with either qp.quantity_from_unit_zero() or qp.quantity_from(some_origin) member functions, which is at least cumbersome.
2. No text output for points – A point's textual representation depends on its origin, which is often implicit or user-defined. As of today, we do not have the means to provide a text symbol for the point origin. Moreover, points may contain both an absolute and a relative origin at the same time, which makes it harder to determine which origin to use for printing. Also, the same point may be represented in many ways (different deltas from various origins). Should such a point have the same or a different textual output for each representation?
3. Error-prone simplifications – Developers frequently replace points with deltas for convenience, losing safety and physical clarity. This is the most dangerous pain point, because it compiles silently. In V2, both quantity<K> and quantity<deg_C> are deltas and are numerically interchangeable. A function accepting quantity<K> will silently accept 20 * deg_C, using the numeric value 20 instead of 293.15. Thermodynamic expressions such as Carnot efficiency will then produce results that are off by a factor of roughly 15, with no compiler warning and no runtime error — the bug is invisible until you check the numbers.

Example

Mass Balance in Drying Process

A food technologist is drying several samples of a specific product to estimate its change in moisture content (on a wet basis) during the drying process.

Simple but error-proneSafer but cumbersome

quantity<percent> moisture_content_change(quantity<kg> water_lost, // delta
                                          quantity<kg> total)      // absolute
{
  gsl_Expects(is_gt_zero(total));
  return water_lost / total;
}

quantity<kg> initial[] = { 2.34 * kg, 1.93 * kg, 2.43 * kg };
quantity<kg> dried[] = { 1.89 * kg, 1.52 * kg, 1.92 * kg };

quantity total_initial = std::reduce(std::cbegin(initial), std::cend(initial));
quantity total_dried = std::reduce(std::cbegin(dried), std::cend(dried));

std::cout << "Initial product mass: " << total_initial << "\n";
std::cout << "Dried product mass: " << total_dried << "\n";
std::cout << "Moisture content change: " << moisture_content_change(total_initial - total_dried, total_initial) << "\n";

quantity<percent> moisture_content_change(quantity<kg> water_lost,
                                          quantity_point<kg> total)
{
  gsl_Expects(is_gt_zero(total));
  return water_lost / total.quantity_from_unit_zero();
}

quantity_point<kg> initial[] = { point<kg>(2.34), point<kg>(1.93), point<kg>(2.43) };
quantity_point<kg> dried[] = { point<kg>(1.89), point<kg>(1.52), point<kg>(1.92) };

auto point_plus = [](QuantityPoint auto a, QuantityPoint auto b){ return a + b.quantity_from_unit_zero(); };
quantity_point total_initial = std::reduce(std::cbegin(initial), std::cend(initial), point<kg>(0.), point_plus);
quantity_point total_dried = std::reduce(std::cbegin(dried), std::cend(dried), point<kg>(0.), point_plus);

std::cout << "Initial product mass: " << total_initial.quantity_from_unit_zero() << "\n";
std::cout << "Dried product mass: " << total_dried.quantity_from_unit_zero() << "\n";
std::cout << "Moisture content change: " << moisture_content_change(total_initial - total_dried, total_initial) << "\n";

In the above example:

• water_lost should be a delta (difference in mass),
• total should conceptually be non-negative absolute amount of mass, yet the type system doesn’t enforce it.

Semantics

This section details the semantics of absolute quantities, their relationship to other abstractions, and how they interact in code and mathematics. It clarifies the rules, conversions, and algebraic properties that underpin the new model.

Position of Absolute Quantities Among Abstractions

Feature	Point	Absolute	Delta
Interpolation	✓	✓	✓
Multiplication / Division	✗	✓	✓
Addition	✗	✓	✓
Subtraction	✓	✓	✓
May be non‑negative	✓	✓	✗
Zero reference	Explicit origin	Anchored at true zero	N/A
Can use offset units	✓	✗	✓
Convertible to offset units	Via offset	✗	No offset
Text output	✗	✓	✓

Absolute quantities sit logically between points and deltas: they behave like deltas algebraically, yet conceptually reference a true zero. This design simplifies arithmetic, improves printing, and preserves physical meaning.

As we can see above, absolute quantities have only two limitations, and both are connected to the use of offset units. They can't use those because they must remain absolute instead of being measured relative to some custom origin.

Simplified API in V3

As I mentioned in my previous post, we are seriously considering removing the quantity_point class template and replacing it with a quantity_spec point wrapper. For example, quantity_point<isq::altitude[m]> will become quantity<point<isq::altitude[m]>>.

I initially planned quantity<isq::mass> to be the same as quantity<delta<isq::mass>>, but it turns out that deltas probably should not be the default. It is consistent with how we write physical expressions on paper, right? The delta symbol (∆) is always "verbose" in physical equations. It would be nice for the C++ code to do the same. So, starting with mp-units V3, deltas will always need to be explicit.

And this brings us to absolute quantities. As we stated in the previous chapter, they could be considered:

• deltas against nothing, and
• points from a well-established zero.

This leads us to the observation that they are the perfect default we are looking for. If we take any physics books, such quantities are the ones that we see in most of the physical equations. This is why we will not need any specifier to denote them in mp-units V3.

Here are some simple examples:

quantity q1 = 20 * kg;        // absolute quantity (measured from true zero)
quantity q2 = delta<kg>(20);  // delta quantity (difference)
quantity q3 = point<kg>(20);  // point quantity (relative to an origin)

The above will produce the following types:

static_assert(std::is_same_v<decltype(q1), quantity<kg>>);
static_assert(std::is_same_v<decltype(q2), quantity<delta<kg>>>);
static_assert(std::is_same_v<decltype(q3), quantity<point<kg>>>);

This mirrors the way physicists write equations: absolute values by default, with explicit Δ when needed.

Alignment with scientific practice

The proposed abstractions mirror the way quantities are treated in physics and engineering textbooks:

• Absolute quantities (e.g., mass, energy, length) are always measured from a natural zero and are mostly non-negative.
• Points (e.g., position, temperature on a relative scale) are always defined relative to an origin.
• Deltas (differences) are the result of subtracting two points or two absolutes.

The following table maps each abstraction to its measurement scale, mathematical structure, physical meaning, and typical C++ representation:

Concept	Measurement Scale	Mathematical Structure	Physical Meaning	Example
Point	Interval Scale	Affine Space	A location on a scale or in space.	point<mass>, point<time>, point<altitude>, point<position_vector> (vector), point<velocity> (vector)
Delta	—	Vector Space	A change, displacement, or interval.	delta<mass>, delta<duration>, delta<height>, displacement (vector), velocity (vector)
Absolute	Ratio Scale	Convex Cone (\(\ge 0\))	A magnitude measured from a true zero.	mass, duration, height, distance (scalar), speed (scalar)

This correspondence ensures that code written with mp-units is not only type-safe, but also directly maps to the equations and reasoning found in scientific literature. This makes code easier to review, verify, and maintain.

Scalar and Vector Quantities

Absolute quantities are always scalar. Vector quantities — those with direction — are inherently signed and therefore always modeled as deltas in mp-units. There is no such thing as an "absolute vector quantity".

Named vector quantities such as displacement and velocity are already deltas by their physical nature, so the delta<> wrapper is neither needed nor used for them:

Quantity	Scalar	Vector
Point	point<time>, point<altitude>, point<mass>	point<position_vector>, point<velocity>
Delta	delta<duration>, delta<height>, delta<mass>	displacement, velocity (no delta<> wrapper needed)
Absolute	duration, height, mass	(none — use norm() to obtain a scalar absolute)

To obtain a scalar absolute from a vector delta, take its norm:

quantity<displacement[m]> v = ...;     // vector delta
quantity<distance[m]>     d = norm(v); // scalar absolute

For signed scalar deltas, abs() (or equivalently .absolute()) converts a delta to an absolute:

quantity d1 = delta<height[m]>(-3);  // signed scalar delta
quantity d2 = abs(d1);               // scalar absolute — same as d1.absolute()

Conversions Between Abstractions

As absolute quantities share properties of both deltas and points with implicit point origins, they should be explicitly convertible to those:

quantity<delta<kg>> q1(20 * kg);
quantity<point<kg>> q2(20 * kg);

or

quantity<delta<kg>> q1 = (20 * kg).delta();
quantity<point<kg>> q2 = (20 * kg).point();

The opposite is not always true:

• not every delta will be a positive amount against nothing,
• not every point on the scale will be positive (e.g., altitudes).

This is why it is better only to expose named functions to convert points and deltas to absolute quantities:

quantity<kg> q3 = q1.absolute();  // may fail the pre-condition check if negative
quantity<kg> q4 = q2.absolute();  // may fail the pre-condition check if negative

It is important to note that conversions between absolute quantities and points should be available only when there is no point origin specified for a point (the point uses an implicit point origin — no explicit origin).

If the user provided an explicit origin, then such a quantity can only be used as a delta:

inline constexpr struct nhn_sea_level : absolute_point_origin<isq::altitude> {} nhn_sea_level;

quantity<m> alt1 = 42 * m;
quantity<point<m>> alt2(alt1);                     // OK
// quantity<point<m>, nhn_sea_level> alt3(alt1);   // Compile-time error
quantity<point<m>, nhn_sea_level> alt4 = nhn_sea_level + alt1.delta();

If the user used an offset unit, then a conversion should work fine as long as the point origin of the offset unit is defined in terms of the implicit point origin:

quantity<K> temp1 = 300 * K;
quantity<point<K>> temp2(temp1);                   // OK
quantity<point<C>> temp3(temp1);                   // OK

To summarize:

From \ To	Point	Absolute	Delta
Point	Identity; point_for(origin) to change representation	.absolute() (if not offset unit and the origin is natural_point_origin); otherwise (point - origin_or_qp).absolute()	point - origin_or_qp; delta_from(origin_or_qp)
Absolute	Explicit ctor (using natural_point_origin); .point()	Identity	Implicit construction; .delta()
Delta	origin + delta → point	.absolute() (precondition: non-negative); always safe: abs(), norm(), or modulus()	Identity

Arithmetic Semantics

Affine space arithmetic is well-defined and commonly used in physics and engineering. With the introduction of absolute quantities, it is important to clarify the meaning of arithmetic operations involving points, absolutes, and deltas.

Addition

Adding two absolute quantities (e.g., \(10\ \mathrm{kg} + 5\ \mathrm{kg}\)) produces another absolute quantity. This is simply the sum of two non-negative amounts, both measured from the true zero of the physical property.

Adding a delta to an absolute quantity (e.g., \(10\ \mathrm{kg} + (-2\ \mathrm{kg})\)) yields an absolute quantity. The zero-anchor principle applies: a signed delta shifts the value but does not destroy the true-zero anchor, so the result remains an absolute. For quantity specs marked non_negative (e.g., isq::mass), a runtime contract check fires if the result would be negative — the check fires at the arithmetic operation site, not at a later conversion step.

Adding an absolute quantity or delta to a point yields a point shifted by the given amount.

Here is the summary of all the addition operations:

Lhs \ Rhs	Point	Absolute	Delta
Point		Point	Point
Absolute	Point	Absolute	Absolute
Delta	Point	Absolute	Delta

Info

Here are some numerical examples that present the available operations and their results:

quantity abs = isq::height(42 * m);
quantity pt = point<isq::altitude[m]>(10);
quantity d = delta<isq::height[m]>(2);
quantity res1 = abs + abs;                 // Absolute
quantity res2 = pt + abs;                  // Point
quantity res3 = d + abs;                   // Absolute

Subtraction

Subtraction in the context of physical quantities is best understood as finding the difference between two amounts.

Subtracting two absolute quantities (e.g., \(50\ \mathrm{kg} - 5\ \mathrm{kg}\)) yields a delta (difference), which may be negative or positive. This is consistent with the mathematical and physical meaning of subtraction.

If an absolute result is needed (e.g., remaining mass), it should be obtained via an explicit conversion:

quantity<kg> remaining = (total - used).absolute();

This rule prevents invalid negative absolutes while remaining explicit when needed.

Subtracting a delta from an absolute quantity (e.g., \(10\ \mathrm{kg} - 2\ \mathrm{kg}\)) yields an absolute quantity. The zero-anchor principle applies: removing a signed change from a zero-anchored value preserves the zero-anchor. For non_negative specs, a runtime contract check fires at the subtraction site if the result would be negative. To intentionally obtain a signed result that may go negative, demote the absolute to a delta first: abs.delta() - d.

Subtracting an absolute quantity from a point yields a point, and subtracting a point from an absolute quantity is not meaningful.

Subtracting an absolute quantity from a delta (e.g., \(2\ \mathrm{kg} - 10\ \mathrm{kg}\)) also yields a delta. The result has no guarantee of positivity — the library cannot determine at compile time whether the delta exceeds the absolute — so the type conservatively remains a delta.

Here is a summary of all of the subtraction operations

Lhs \ Rhs	Point	Absolute	Delta
Point	Delta	Point	Point
Absolute		Delta	Absolute
Delta		Delta	Delta

Info

Here are some numerical examples that present the available operations and their results:

quantity abs = isq::height(42 * m);
quantity pt = point<isq::altitude[m]>(10);
quantity d = delta<isq::height[m]>(2);
quantity res1 = pt - abs;                  // Point
// quantity res2 = abs - pt;               // Compile-time error
quantity res3 = abs - pt.absolute();       // Delta or quantity_difference
quantity res4 = abs - d;                   // Absolute
quantity res5 = d - abs;                   // Delta

Magnitude and Ratio Operations

Beyond addition and subtraction, the following table summarises the multiplication, division, and magnitude operations involving absolute quantities and deltas:

Operation	Result	Notes
Absolute × Absolute	Absolute	A product of two absolute quantities (e.g., energy = power × time).
Absolute × Scalar	Absolute	Rescaling by a dimensionless factor (e.g., 2 × mass stays absolute mass).
Absolute × Delta	Delta	Absolute scaled by a displacement (e.g., area × delta_height → delta_volume).
Delta × Absolute	Delta	Same as Absolute × Delta — multiplication is commutative.
Delta × Scalar	Delta	Rescaling a signed difference (factor preserves delta category).
Absolute / Absolute	Absolute	A physical ratio (e.g., efficiency, strain, density).
Absolute / Delta	Delta	Rate of an absolute with respect to a signed step.
Delta / Absolute	Delta	A change scaled by a fixed magnitude.
Delta / Delta	Delta	A rate of change (e.g., velocity = displacement / duration).
abs(delta_scalar)	Absolute	Magnitude of a scalar delta. Equivalent to delta.absolute().
modulus(delta_complex)	Absolute	Modulus of a complex scalar delta.
norm(delta_vector)	Absolute	Magnitude of a vector delta (e.g., speed = norm(velocity)).

The last two rows highlight the two pathways from a delta to an absolute:

• For scalar deltas: abs(d) or equivalently d.absolute() — both check the non-negativity precondition at runtime.
• For vector deltas: norm(v) — the Euclidean norm, which is always non-negative by definition.

Interpolation

Interpolation of absolute quantities (e.g., finding a value between \(a\) and \(b\)) is well-defined and results in another absolute quantity. This is commonly used in physics and engineering for averaging, blending, or estimating values between two known points.

Non-negativity

Non-negativity of absolute quantities is meant to be an opt-in feature in the quantity specification. For example, we can pass a non_negative tag type in quantity definition:

inline constexpr struct mass : quantity_spec<dim_length, non_negative> {} mass;

With that, we will be able to mark any quantity as non-negative and this property will be inherited by the subquantities in the quantity hierarchy tree of the same kind.

Deriving non-negativity automatically from equation factors is explicitly not done. A defining equation captures only dimensional relationships, not the full sign domain of a physical quantity. Many physically signed quantities have equations where every factor is non-negative (e.g., thermal expansion coefficient, reactive power, Massieu function), so inferring sign from the equation would silently misclassify them. Instead, every non-negative root derived quantity carries an explicit non_negative tag at its definition. Named children inherit the tag from their parent; ad-hoc anonymous composed specs (e.g., isq::length / isq::time) are never non-negative unless they resolve to a named quantity that carries the tag.

The non_negative precondition is checked at three sites:

1. Construction — building an absolute from a literal or from a delta value.
2. .absolute() conversion — promoting a delta or point to an absolute.
3. Absolute ± Delta arithmetic — at the arithmetic site, before the result is stored.

One important subtlety: kind_of<QS> is never non_negative, even when QS carries the tag. Kind-erased quantities can represent any quantity of that kind — some of which are signed — so the constraint is intentionally dropped.

Unary negation of a non_negative absolute is an open design question: the two candidate behaviors are a compile-time error (safest) or implicit demotion to a delta (most convenient). Either way, the result is never an absolute.

Interesting Quantity Types

Time

Let's look closer at the quantity of time. There is no way to measure its absolute value as we don't even know where (when?) the time axis starts... Only time points and time deltas (durations) make sense.

However it seems that the ISQ thought this through already. It does not define a quantity of time at all. It only provides duration defined as:

ISO 80000-3:2019

name: duration

symbol: \(t\)

Definition: measure of the time difference between two events

Remarks: Duration is often just called time. Time is one of the seven base quantities in the International System of Quantities, ISQ (see ISO 80000-1). Duration is a measure of a time interval.

As long as absolute quantity<isq::time[s]> may seem off, quantity<isq::duration[s]> is OK as an absolute quantity. Durations typically should be non-negative as well. If we need a negative duration then quantity<delta<isq::duration[s]>> makes sense.

isq::time should be reserved for affine space point only (e.g., quantity<point<isq::time>[s]>). You can find more about this in my Bringing Quantity-Safety To The Next Level blog article.

The above does not mean that we should always use typed quantities for time. We can still use simple quantities and the library will reason about them correctly:

• quantity<s> or 42 * s -> absolute duration
• quantity<delta<s>> or delta<s>(-3) -> delta duration
• quantity<point<s>> or point<s>(94573457438583) -> time point

Length

A somewhat similar case might be the length quantity, as there is no one well-established zero origin that serves as a reference for all length measurements. However, asking the users always to provide a delta specifier for length would probably be overkill. Everyone can imagine what no length/radius/height means. Also, most of us are okay with each object having its own length measurement origin.

Note

In the context of absolute quantities, quantity<m> always represents a size (such as the length, width, or height of an object), not a position in space.

Positions are modeled using the point<m> abstraction, which always refers to a location relative to a defined origin.

This distinction ensures that code using absolute quantities for size cannot be confused with code representing positions. For example, quantity<m> is used for the length of a rod, not its position in space.

Electric Current

Electric current is the only ISQ base quantity that has a well defined zero point (no current flow in the wire), but its values can be both positive and negative depending on the direction the current flows.

We could be tempted to model electric current as the 1-dimensional vector quantity, but probably it is not the best idea. It is officially defined as a signed scalar quantity.

Absolute electric current values should be available, but should not perform a non-negative precondition check on construction and assignment.

Temperature

As we pointed out before, it will be possible to form absolute quantities of temperature, but only when the unit is (potentially prefixed) Kelvin. For offset units like degree Celsius, it will not be possible.

The reason runs deeper than a mere unit-system rule. Kelvin temperature encodes thermodynamic energy content: the mean molecular kinetic energy of an ideal gas is proportional to \(k_B T\), where \(T\) must be an absolute temperature. This makes Kelvin a ratio scale quantity — ratios and products involving \(T\) are physically meaningful (\(T_h / T_c\) in the Carnot efficiency, \(nRT\) in the ideal gas law). Degree Celsius, by contrast, is an interval scale: only differences of Celsius temperatures are physically meaningful, not their ratios or products. A Celsius value of \(20\ ^\circ\mathrm{C}\) is not "twice as hot" as \(10\ ^\circ\mathrm{C}\).

This distinction is exactly what the Point/Absolute split captures:

• quantity<K> — Absolute: ratio-scale magnitude, safe in multiplicative expressions.
• quantity<point<deg_C>> — Point: interval-scale location, blocked in multiplicative expressions by the type system.

If the user has a temperature point in Celsius and wants to treat it as an absolute quantity and pass it to some quantity equation, then such point first needs to be converted to use Kelvin as its unit and then we need to create an absolute quantity from it:

quantity temp = point<deg_C>(21);
quantity kinetic_energy = 3 / 2 * si::boltzmann_constant * temp.in(K).absolute();

The explicit .in(K).absolute() chain is a type-safety checkpoint: it ensures the programmer consciously acknowledges the shift from an interval-scale location to a ratio-scale magnitude, preventing the silent 20 vs. 293.15 error described in the Current Pain Points section above.

Which Quantity Abstraction Should I Use?

The decision tree below provides guidance on choosing the appropriate quantity abstraction for a specific use case. Start with the first question and follow the path based on your answers:

flowchart TD
    ask_point{{Adding two quantities of this type makes sense?}}
    ask_point -- No --> Point[Point]
    ask_point -- Yes --> ask_delta{{Possibly negative difference/distance between two quantities?}}
    ask_delta -- Yes --> Delta[Delta]
    ask_delta -- No --> Absolute[Absolute]

    %% Styling
    classDef pointStyle fill:#c0392b,stroke:#e74c3c,stroke-width:2px,color:#fff
    classDef deltaStyle fill:#27ae60,stroke:#2ecc71,stroke-width:2px,color:#fff
    classDef absoluteStyle fill:#2980b9,stroke:#3498db,stroke-width:2px,color:#fff
    classDef questionStyle fill:#d4a017,stroke:#f0b429,stroke-width:2px,color:#fff

    class Point pointStyle
    class Delta deltaStyle
    class Absolute absoluteStyle
    class ask_point,ask_delta questionStyle

Bug Prevention and Safety Benefits

The new model eliminates a class of subtle bugs that arise from conflating positions, sizes, and differences. For example:

• No accidental addition of positions
  • the type system prevents adding two point<m> objects, which is physically meaningless
• No silent sign errors
  • subtracting two absolute quantities always yields a delta, so negative results are explicit and must be handled intentionally
• No misuse of offset units
  • absolute quantities cannot be constructed with offset units (like Celsius), preventing incorrect temperature calculations
• Compile‑time enforcement
  • most mistakes caught before runtime

Revised Example

Let's revisit our initial example. Here is what it can look like with the absolute quantities usage:

Mass Balance in Drying Process

A food technologist is drying several samples of a specific product to estimate its change in moisture content (on a wet basis) during the drying process.

quantity<delta<percent>> // (1)!
moisture_content_change(quantity<delta<kg>> water_lost, // (2)!
                        quantity<kg> total) // (3)!
{
  // gsl_Expects(is_gt_zero(total)); (4)
  return water_lost / total;
}

quantity<kg> initial[] = { 2.34 * kg, 1.93 * kg, 2.43 * kg }; // (5)!
quantity<kg> dried[] = { 1.89 * kg, 1.52 * kg, 1.92 * kg };

quantity total_initial = std::reduce(std::cbegin(initial), std::cend(initial)); // (6)!
quantity total_dried = std::reduce(std::cbegin(dried), std::cend(dried));

std::cout << "Initial product mass: " << total_initial << "\n"; // (7)!
std::cout << "Dried product mass: " << total_dried << "\n";
std::cout << "Moisture content change: " << moisture_content_change(total_initial - total_dried, total_initial) << "\n"; // (8)!

1. Theoretically a negative result is possible if the product gained water in the process of drying.
2. Explicit delta.
3. Absolute quantity.
4. No longer needed as absolute quantities of mass will have a precondition of being non-negative.
5. Simple initialization of absolute quantities.
6. Arithmetic works.
7. Test output works.
8. Type safe!

This version is concise, physically sound, and type‑safe. Function arguments can't be reordered and non‑negativity guarantees remove the need for manual runtime checks.

Migration and Backward Compatibility

Although the theory in the chapters above may seem intimidating, users will not be significantly affected by the changes in mp-units V3.

As we can see, the new code above does not differ much from our previously unsafe but favored version. The only difference is that we spell delta explicitly now, and that we can safely assume that absolute values of mass are non-negative. The rest looks and feels the same, but the new solution is safer and more expressive.

The biggest migration challenge is related to the results of subtraction on two quantities, points, or deltas. From now on, they will result in a different type (i.e., quantity<delta<...>>) which is not implicitly convertible to an absolute quantity.

BeforeAfter

quantity<km / h> avg_speed(quantity<km> distance, quantity<h> duration)
{
  return distance / duration;
}

quantity_point<km> odo1 = ...;
quantity_point<s> ts1 = ...;
quantity_point<km> odo2 = ...;
quantity_point<s> ts2 = ...;
// quantity res = avg_speed(odo2 - odo1, ts2 - ts1);  // Compile-time error

quantity<km / h> avg_speed(quantity<km> distance, quantity<h> duration)
{
  return distance / duration;
}

quantity_point<km> odo1 = ...;
quantity_point<s> ts1 = ...;
quantity_point<km> odo2 = ...;
quantity_point<s> ts2 = ...;
quantity res = avg_speed((odo2 - odo1).absolute(), (ts2 - ts1).absolute());  // OK

In case of an invalid order of subtraction arguments, the precondition check will fail at runtime only for the conversion to absolutes case. This increases the safety of our code.

Another migration challenge may be related to the usage of negative values. All of the ISQ base quantities besides electric current could be defined to be non-negative for absolute quantities. This means that if a user is dealing with a negative delta today, such code will fail the precondition check in the absolute quantity constructor. To fix that, the user will need to use explicit delta specifiers or construction helpers in such cases:

quantity<m> d1 = -2 * m;       // Precondition check failure at runtime
quantity<delta<m>> d2(-2 * m); // Precondition check failure at runtime
quantity d3 = delta<m>(-2);    // OK

Regarding temperature support, in the Semantics chapter, we said that a new abstraction will not work for offset units. However, it was also the case in mp-units V2. If we check The Affine Space chapter we will find a note that:

Quote

The multiply syntax support is disabled for units that provide a point origin in their definition (i.e., units of temperature like K, deg_C, and deg_F).

We always found those confusing and required our users to be explicit about the intent with point and delta construction helpers. So nothing changes here from the coding point of view. From the design point of view, we replace some strange corner case design constraint with a properly named abstraction that models that behavior.

Actually, V3 will improve temperature support significantly. Thanks to the new abstraction, we will be able to multiply and divide absolute temperatures with other quantities, but only if the temperature is measured in Kelvin. Also, the multiply syntax will work to construct such absolute quantities (e.g., \(300 \times \mathrm{K}\)).

Last, but not least, the quantity_point<...> class template will be replaced with quantity<point<...>> syntax.

Key Migration Rules

V2 Pattern	V3 Equivalent	Notes
quantity<kg>	quantity<kg>	Before delta and now absolute
quantity<kg> m = m1 - m2;	quantity<kg> m = (m1 - m2).absolute();	Explicit if you want abs
quantity<kg> dm = m1 - m2;	quantity<delta<kg>> dm = m1 - m2;	Explicit deltas when negative value possible
quantity_point<kg> p = ...;	quantity<point<kg>> p = ...	Use point<kg> wrapper
quantity<kg> d = p - point<kg>(42);	quantity<delta<kg>> d = p - point<kg>(42);	Deltas must be explicit

Most user code will continue to compile after adding explicit delta or .absolute() conversions where needed.

Rationale

Here we discuss the rationale behind the proposed changes, including the design philosophy, alignment with scientific practice, and the benefits for standardization and future extensibility.

Non-negativity in Physical Equations vs API Design

In most physical equations, the quantities we work with are expected to be non-negative amounts. For example, mass, energy, distance, and duration are all inherently non-negative in physical reality. While the mathematical abstraction of a delta (difference) allows for negative values, in practice, negative deltas are rare or even unphysical in many domains.

Consider the case of speed:

Quote

Speed is defined as the ratio of a change in length (distance traveled) to a change in time (duration):

\(speed = \frac{\Delta length}{\Delta time}\)

While the formula uses deltas, in almost all practical scenarios, both \(\Delta length\) and \(\Delta time\) are non-negative. A negative duration, for example, is not physically meaningful and would indicate a logic error in most applications.

Prefer absolute quantities for non-negative deltas

This has important implications for API design. If a function like avg_speed accepts deltas as arguments, users might inadvertently pass negative values, leading to nonsensical results or subtle bugs:

// Problematic: allows negative duration
quantity<m/s> avg_speed(quantity<delta<m>> distance, quantity<delta<s>> duration)
{
  return distance / duration;
}

Instead, it is safer and more physically correct to require absolute quantities for such parameters, leveraging the fact that ISQ provides distance and duration as non-negative quantities:

SimpleTyped

// Safer: enforces non-negativity
quantity<m/s> avg_speed(quantity<m> distance, quantity<s> duration)
{
  return distance / duration;
}

// Safer: enforces non-negativity
quantity<isq::speed[m/s]> avg_speed(quantity<isq::distance[m]> distance, quantity<isq::duration[s]> duration)
{
  return distance / duration;
}

This approach ensures that only non-negative values can be passed, preventing negative durations or distances from entering your calculations. This reduces the risk of bugs, makes your code more robust, and better reflects the intent of most physical equations.

New opportunities

The new syntax allows us to model quantities that were impossible to express before without some workarounds.

For example, we can now correctly calculate Carnot engine efficiency with any of the following:

quantity temp_cold = 300. * K;
quantity temp_hot = 500. * K;
quantity carnot_eff_1 = 1. - temp_cold / temp_hot;
quantity carnot_eff_2 = (temp_hot - temp_cold) / temp_hot;

In the above code, we can easily create absolute or delta values of temperatures and perform arithmetic on them. Previously, we had to create deltas from both points artificially with:

quantity temp_cold = point<K>(300.);
quantity temp_hot = point<K>(500.);
quantity carnot_eff_1 = 1. - temp_cold.quantity_from_unit_zero() / temp_hot.quantity_from_unit_zero();
quantity carnot_eff_2 = (temp_hot - temp_cold) / temp_hot.quantity_from_unit_zero();

It worked, but was far from being physically pure and pretty.

Why Obvious Workarounds Fall Short

Two workaround approaches exist, each with its own caveat.

Approach 1: quantity_from_unit_zero()

quantity_from_unit_zero() returns the displacement of a quantity point from its unit's origin. For Kelvin this is si::absolute_zero, so the result is exactly the thermodynamic temperature:

point<K>(294.15).quantity_from_unit_zero();  // 294.15 K ✓

For Celsius, however, the unit's origin is si::ice_point — the ice point. The function therefore returns the displacement from the ice point, not from absolute zero:

point<deg_C>(21).quantity_from_unit_zero();  // 21 ℃ — displacement from ice point, not 294.15 K!

This is a silent pitfall: the call compiles and returns a plausible-looking value for any temperature unit, but is only thermodynamically meaningful when the point is already in Kelvin. Explicit conversion before the call fixes it:

point<deg_C>(21).in(K).quantity_from_unit_zero();  // 294.15 K ✓

Approach 2: Subtract si::absolute_zero

Subtracting the absolute-zero origin always gives the correct thermodynamic temperature regardless of the unit the point was stored in:

quantity_point temp = point<deg_C>(21);
quantity T = temp - si::absolute_zero;  // always correct

The only thing to be aware of is the resulting unit. Because si::ice_point (the origin of the Celsius scale) is defined internally in milli<kelvin>, the subtraction yields mK rather than K:

T == 294150 mK   // correct value, can be rescaled with .in(K)

The value is correct and rescales cleanly to any unit. In a physical equation like the ideal gas law, p will come out in mPa instead of Pa, but it will convert automatically on the first assignment to a typed quantity such as quantity<Pa>.

The bottom line

Both approaches work correctly when used with care. quantity_from_unit_zero() is concise but requires the point to already be in Kelvin; subtraction from si::absolute_zero is always safe but carries an mK unit until rescaled. In either case, the right idiom — .in(K).quantity_from_unit_zero() — must be remembered and applied at every call site, and there is no way to enforce it through the type system.

V3 Absolute Quantities address this: 300 * K is already an Absolute Quantity, directly usable in any multiplicative expression. When an offset-unit point must enter a thermodynamic equation, the explicit .in(K).absolute() chain makes the conversion visible and type-safe — exactly once, at the boundary.

Design Philosophy and Standardization

Absolute quantities make physical semantics explicit while simplifying common use cases. They expose existing conceptual complexity rather than adding new layers. The design is:

• Consistent with ISQ – mirrors the distinction between displacement, position, and difference.
• Predictable – clear subtraction and conversion rules.
• Scalable – a single quantity class handles all variants via wrappers.
• Safe – non‑negativity and offset‑unit rules prevent misuse.
• Extensible – additional quantity abstractions may be added in the future by simply introducing a new wrapper.

For standardization, this model brings three tangible benefits:

1. Closer alignment with physical reasoning used by scientists and engineers.
2. Improved readability and verification in generic C++ code.
3. Zero runtime overhead — all checks are compile‑time or lightweight preconditions.

Mathematical Grounding: Ratio Scale and Convex Sets

The term Ratio Scale used throughout this article comes from measurement theory (Stevens, 1946) and is standard in metrology (VIM) and physics. A ratio scale has a true physical zero so that ratios of values are meaningful: \(2\ \mathrm{kg}\) is genuinely twice as much as \(1\ \mathrm{kg}\), whereas \(40\ ^\circ\mathrm{C}\) is not twice as hot as \(20\ ^\circ\mathrm{C}\).

Convex Cone is the corresponding mathematical structure: the set of all admissible values of a ratio-scale quantity is the non-negative half-line \([0, +\infty)\), which is a convex cone — it is closed under addition and under multiplication by a non-negative scalar. Requests for a "validator" or "convex space" abstraction in quantities libraries are describing exactly this property.

The two terms therefore describe the same thing from two complementary angles: Ratio Scale is the measurement-theory characterisation (what operations are physically meaningful), while Convex Cone is the algebraic-structure characterisation (what set the values live in). Both appear in the literature and both are correct; the Alignment with scientific practice table in the Semantics section shows all three columns side-by-side.

The .absolute() conversion method is the explicit, type-safe crossing from an Interval-Scale Affine Space (Points) or an unrestricted Vector Space (Deltas) into the Ratio-Scale Convex Cone (Absolutes). Rather than relying on a separate validation layer or runtime validators, the type system itself encodes the constraint — providing the mathematical rigor that metrology and physics demand.

Frequently Asked Questions: The V3 Physical Model

As mp-units moves toward a more rigorous modeling of physical spaces, several questions arise regarding the distinction between Points, Deltas, and Absolute Quantities. This Q&A addresses the most common technical and philosophical inquiries.

---

1. Why do we need "Absolute Quantities" if we already have "Delta Quantities"?

While both can share the same underlying representation (e.g., double), they represent different mathematical structures.

• Delta Quantities belong to a Vector Space. They represent a displacement, can be negative, and lack a natural origin.
• Absolute Quantities belong to a Ratio Scale. They represent a magnitude measured from a unique, non-arbitrary physical zero (like \(0\text{ K}\) or \(0\text{ kg}\)).

Without the Absolute abstraction, the library cannot distinguish between a Change in Temperature (\(\Delta 20\text{ K}\)) and a State of Temperature (\(20\text{ K}\) absolute). This leads to the "Offset Unit Trap," where a user might accidentally plug \(20^\circ\text{C}\) (a delta) into an ideal gas law equation, yielding a result off by a factor of 15.

---

2. Is Velocity a Delta or an Absolute Quantity?

Velocity is a Delta Quantity (Vector). It represents a displacement over time and carries direction (or a sign in 1-D).

Speed is an Absolute Quantity (Scalar). It is the magnitude (norm) of that velocity.

In V3, we use the type hierarchy to model this: velocity is a child of speed. When you call norm(velocity), the type "decays" from the Vector-Delta space to the Absolute-Scalar space.

---

3. Why does Absolute ± Delta result in an Absolute?

One might expect that, since a delta can be negative, the result of Absolute ± Delta should be conservatively typed as a Delta. This was the initial design — but it was rejected in favour of the zero-anchor principle.

The key insight is that the category of a quantity describes where it lives, not what sign it has. A delta has no fixed origin; an absolute is anchored at a physically meaningful true zero. Adding or subtracting a signed displacement does not destroy that anchor — the result is still measured from the same true zero:

• tank(500 kg, absolute) + refuel(200 kg, delta) → 700 kg (absolute)
• tank(500 kg, absolute) - burn(600 kg, delta) → −100 kg (absolute)

The second case is a value-range violation, not a type-category error. For quantity specs marked non_negative (e.g., isq::mass), a runtime contract check fires at the ± operation site when the result would be negative. To intentionally work in the signed domain — for example, to represent a deficit that may go negative — demote first: fuel.delta() - burn produces delta<mass>: −100 kg with no check.

This rule is also consistent with Absolute × Scalar → Absolute: multiplying by a negative scalar can drive an absolute below zero, yet no one questioned the result type there. Both are value-range issues handled by runtime checks, not compile-time type demotions.

---

4. Why is Absolute × Delta a Delta, but Absolute ± Delta an Absolute?

Both rules follow the same zero-anchor principle, which asks: does the operation preserve the true-zero anchor?

Addition/subtraction — translating a zero-anchored value up or down does not move the anchor. The result is still measured from the same physical zero, so it remains an absolute:

\[\text{tank} + \Delta\text{refuel} = \text{new tank level, still measured from 0 kg}\]

Multiplication — when you multiply an absolute by a delta, you are combining two different quantities into a third (e.g., power × time → energy, or area × delta_height → delta_volume). The delta carries orientation-awareness (it can be negative). The resulting derived quantity inherits that orientation-awareness: the product can be negative simply because the delta is negative, and there is no single physically meaningful true zero shared by both factors. The zero-anchor is not preserved, so the result is a Delta.

In code:

quantity fuel      = isq::mass(500 * kg);          // absolute
quantity burn      = delta<isq::mass[kg]>(600);    // delta (signed change)
quantity remaining = fuel - burn;                  // absolute: −100 kg (contract fires for non_negative)

quantity area      = isq::area(10 * m2);           // absolute
quantity dh        = delta<isq::height[m]>(3);     // delta
quantity vol_delta = area * dh;                    // delta: 30 m³ (delta, not absolute)

---

5. How do I handle a deficit without triggering the non-negativity contract?

For quantity specs marked non_negative, the contract fires whenever an Absolute ± Delta result would go below zero. Two escape hatches exist:

Demote before the operation — convert the absolute to a delta first. The result is a delta with no invariant, so the deficit is representable without a contract violation:

quantity fuel        = isq::mass(500 * kg);        // non_negative absolute
quantity consumption = delta<isq::mass[kg]>(600);  // signed delta

quantity balance = fuel.delta() - consumption;     // delta<mass>: −100 kg, no contract
if (balance < delta<isq::mass[kg]>(0)) {
  // handle deficit: 100 kg short
}

Model consumption as an absolute — fuel consumption is a non-negative amount burned, so it is physically better typed as an absolute. Subtracting two absolutes yields a delta via Absolute − Absolute → Delta (the affine-space rule), with no check required:

quantity fuel        = isq::mass(500 * kg);        // absolute
quantity consumption = isq::mass(600 * kg);        // absolute (non-negative burn amount)
quantity balance     = fuel - consumption;         // delta<mass>: −100 kg, no contract
if (balance < delta<isq::mass[kg]>(0)) {
  // handle deficit
}

The second approach is the stronger design: the type of consumption encodes the physical invariant (burn amounts cannot be negative), and the Absolute − Absolute → Delta rule delivers the signed balance naturally.

---

6. Should Time Points be treated the same as Position Points?

Mathematically, both are Affine Spaces. However, they differ in dimensionality:

• Position exists in a 3-D space; its "Deltas" are Vectors (\(\vec{r}\)).
• Time exists in a 1-D space; its "Deltas" are Signed Scalars.

V3 respects this by allowing 1-D deltas to carry a sign bit (direction), whereas Absolute Quantities (like Age or Duration-amount) are strictly non-negative. Treating a 1-D time-delta as a pure scalar is dangerous because it allows directionality to propagate into equations where only magnitude is required.

For example, if you calculate the Total Energy (\(Q = P \times \Delta t\)) during a reverse-time simulation, a negative \(\Delta t\) will result in a negative \(Q\). If that \(Q\) is then used to calculate a required Mass or Volume, you would get a physically impossible negative result.

By distinguishing between a Delta (the step) and an Absolute (the duration magnitude), V3 forces you to be explicit about whether the direction of time matters to your equation.

---

7. Does a + b = c imply the same types work for a = c - b?

Not necessarily. The category of c - b is determined by what c and b are, not by what a was in the original equation. Specifically, Absolute − Absolute → Delta, so if both c and b are absolutes, c - b is a delta even if a was an absolute.

This asymmetry is deliberate: the equation \(a + b = c\) is a statement about values, not about categories. Use .absolute() to convert back explicitly when the value is known to be non-negative.

---

8. Why is Quantity the default for Absolute in V3?

It aligns the library with how physics is taught. In V2, the most "natural" syntax (quantity<K>) was often used to represent deltas, forcing users to use more complex syntax for absolute states. In V3, we align the library with physics textbooks:

• Textbook: \(PV = nRT\) (Uses absolute temperature).
• V3 Code: (P * V) / (n * T) (Uses quantity<K>, which is Absolute by default).

By making Absolute the default, the most common physics equations become the easiest to write and the safest to execute. If you need a point or a delta, you wrap it; if you have a magnitude, you just use it.

---

9. Isn't point.absolute() just more boilerplate?

It is a Type-Safety Checkpoint. When you convert a point<deg_C> to an absolute<K>, you are performing a non-trivial physical transformation (shifting the origin to absolute zero). Forcing the user to call .absolute() ensures that this conversion is intentional. It prevents the silent bug of dividing two "points" and getting a meaningless ratio.

---

10. Is the 3-category model too complex for users?

It has a learning curve, but it maps more closely to how we think. We don't think of "The distance to the moon" as a "Delta of Position" in daily life; we think of it as a magnitude. By providing the Absolute category, we give users a name for the "buckets of stuff" they are actually measuring.

Conclusion

Adding absolute quantities elevates mp-units from a dimensional analysis tool to a true physical reasoning framework. The proposal clarifies semantics, improves safety, and aligns code directly with equations found in textbooks. This is not extra complexity—it's the formalization of the real structure of physical space in C++ types.

We plan to deliver this as part of mp-units V3 and welcome community and WG21 feedback.

Comments
